LUCCA M58 Espresso Machine

The LUCCA M58 is a stainless steel dual boiler, rotary pump, E61 espresso machine with a built-in PID and shot timer that can be direct plumbed or run on its built-in reservoir. Each unit is assembled by hand by Quick Mill in Milan, Italy.

• 2 bar steam pressure
• Stainless steel boilers with 1400W heating elements
• E61 group head
• Resettable hi-limit to protect the heating element
• PID temperature control
• Integrated shot timer accurate to the tenth of a second
• Steam and pump pressure gauges
• Heating indicator lights
• No-burn, stainless steel steam and hot water arms
• Joystick steam and hot water valves
• Direct plumb option (braided water line included)
• Brew boiler: Stainless steel, .75L
• Steam Boiler: Stainless steel, 1.4L
• Reservoir: 3L (with low water sensor)

Housing

• Material: Stainless steel
• Drip Tray: Stainless steel
• Drip Tray Cover: Stainless steel
• Drip Tray Capacity: 1.66 L / 56 oz
• Drainable Drip Tray: Yes, drain kit included

Water Reservoir

• Reservoir or Plumbed: Both
• Capacity: 3 L / 100 oz
• Material: BPA free plastic
• Removable: Yes
• Low Water Shutoff: Yes

Cup warming tray

• Material: Stainless steel

Steam Wand

• Material: Stainless steel
• No Burn (Insulated): Yes
• Wand Movement: Articulating, full rotation
• Steam Tip Holes: 2 and 3 hole included
• Optional Steam Tips: Yes

Portafilters & Tampers

• Materials: Chrome plated brass body, plastic handle with balancing chrome tip
• Type: Commercial 58 mm
• Portafilters Included: 2 (spouted and bottomless)
• Baskets Included: Double, triple, and backflush disk for cleaning
• Tamper Included: Yes

Group head

• Type: E61, lever activated
• Maintenance: Urnex Full Circle or Cafiza backflush detergent

Boilers

• Material: Stainless steel
• Brew Boiler Size: 0.75 L / 25.36 oz
• Steam Boiler Size: 1.4 L / 47.4 oz
• Brew Boiler Power: 1400 W
• Steam Boiler Power:1400 W
• Boilers Automatically Fill: Yes
• Insulated: From the bottom
• Heating Element Access: Yes, velcro wrap

Pump

• Pump Type: Rotary vane, Fluid-o-Tech brand
• Recommended Brew Pressure: 9 bar
• Adjustable Brew Pressure: Yes, externally through side panel

• Temperature: Yes
• Brew Temperature Adjustment: Individual degree (Fahrenheit or Celsius)
• Steam Boiler Adjustment: Individual degree (Fahrenheit or Celsius)
• Display Type: LCD
• Display Can Be Disabled: No
• Integrated Shot Timer: Yes
• Built-In On/Off Timer: No
• Display Cleaning Reminder: No
• Pre-Infusion: Yes, when plumbed in
• Flow Profiling: No
• Volumetric Dosing: No
• Pressure Gauges: 2, pump pressure and steam boiler pressure
